Page #1160 background imageLoading...
Page #1160 background image
Detailed description
2.12 Block descriptions
Power Line Basic PLC Program (P3)
2-248 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
Call example
CALL FC 26 ( //Machine control panel of the HPU/HT6
//signals to interface
BAGNo := B#16#1, //Mode group no. 1
ChanNo := B#16#1); //Channel no. 1
With these parameter settings, the signals from the first parameterized machine control
panel are sent to the 1st mode group, the 1st channel and all axes.
2.12.30 FC 19, FC 24, FC 25, FC 26 source code description
Task
Machine control panel to application interface
(FC 19 M variant, FC 24 slim variant, FC 25 T variant, FC 26 HPU/HT6 variant)
Associated blocks
DB 7 (this was DB 5, up to SW 3), mode group number, channels, axes
DB 7, pointer of machine control panel
DB 8, storage for the next cycle
FC 20, output of error messages
Resources used
None.
