Data Lists
5.3 Signals
Mode Group, Channel, Program Operation, Reset Response (K1)
5-8 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
5.3 5.3 Signals
5.3.1 Signals to NC
DB number Byte.Bit Description
10 56.1 EMERGENCY STOP
5.3.2 Signals to mode group
DB number Byte.Bit Description
11, ... 0.0 AUTOMATIC mode
11, ... 0.1 MDA mode
11, ... 0.2 JOG mode
11, ... 0.4 Mode change disable
11, ... 0.5 Mode group Stop
11, ... 0.6 Mode group Stop axes plus spindles
11, ... 0.7 Mode group RESET
11, ... 1.0 TEACHIN machine function
11, ... 1.1 Machine function REPOS
11, ... 1.2 Machine function REF
5.3.3 Signals from mode group
DB number Byte.Bit Description
11, ... 4.0 Selected mode AUTOMATIC
11, ... 4.1 Selected mode MDA
11, ... 4.2 Selected mode JOG
11, ... 5.0 Selected machine function TEACH-IN
11, ... 5.1 Selected machine function REPOS
11, ... 5.2 Selected machine function REF
11, ... 6.0 Active mode AUTOMATIC
11, ... 6.1 Active mode MDA
11, ... 6.2 Active mode JOG
11, ... 6.3 Mode group ready
11, ... 6.4 Mode group has been reset
11, ... 6.5 Internal Jog is active
11, ... 6.7 All channels in Reset state
