Detailed Description
2.14 Reference point approach (R1)
NC/PLC Interface Signals (Z1)
2-118 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
2.14.4 Signals from axis/spindle (DB31, ...)
DB31, ...
DBX60.4 Referenced/synchronized 1
Edge evaluation: Signal(s) updated:
Signal state 1 or
edge change
0 → 1
Axes:
When being referenced, if the machine axis has reached the reference point (incremental
measuring systems) or the target point (for length measuring system with distance-coded reference
marks), then the machine axis is referenced and the following interface signal is set:
DB31, ... DBX60.4 (referenced/synchronized 1)
(depending on which position measuring system is active when referencing).
Spindles:
After power-on, a spindle is synchronized the latest after one spindle revolution (260 degrees) (the
zero mark passed or the Bero responded).
Signal state 0 or
edge change
1 → 0
The machine axis/spindle with position measuring system 1 is not referenced/synchronized.
Corresponding to .... DB31, ... DBX1.5 (position measuring system 1)
Additional references /FB1/ Description of Functions, Basic Machine; Spindles (S1)
DB31, ...
DBX60.5 Referenced/synchronized 2
Edge evaluation: Signal(s) updated:
Signal state 1 or
edge change
0 → 1
Axes:
When being referenced, if the machine axis has reached the reference point (incremental
measuring systems) or the target point (for length measuring system with distance-coded reference
marks), then the machine axis is referenced and the following interface signal is set:
DB31, ... DBX60.5 (referenced/synchronized 2)
(depending on which position measuring system is active when referencing).
Spindles:
After power-on, a spindle is synchronized the latest after one spindle revolution (260 degrees) (the
zero mark passed or the Bero responded).
Signal state 0 or
edge change
1 → 0
The machine axis/spindle with position measuring system 2 is not referenced/synchronized.
Axes:
Alarm 21610 was output.
Spindles:
Encoder limit frequency exceeded.
Corresponding to .... DB31, ... DBX1.6 (position measuring system 2)
MD34102 $MA_REFP_SYNC_ENCS (measuring system calibration) = 0
Additional references /FB1/ Description of Functions, Basic Machine; Spindles (S1)
