Data Lists
5.4 Signals
Axis Types, Coordinate Systems, Frames (K2)
Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
5-5
Names Description
$P_CHBFRAME[n] Current basic frame in channel,
0 to 15 NCU basic frames can be configured via machine data
MD28081 MM_NUM_BASE_FRAMES.
$P_NCBFRAME[n] Current NCU basic frame,
0 to 15 NCU basic frames can be configured via machine data
MD18602 MM_NUM_GLOBAL_BASE_FRAMES.
$P_ACTBFRAME Current chained total basic frame
$P_BFRAME Current first basic frame in the channel. Corresponds to $P_CHBFRAME
$P_IFRAME Current settable frame
$P_PFRAME Current programmable frame
$P_ACTFRAME Current total frame
$P_UIFRNUM Number of active frame $P_UIFR
$P_NCBFRMASK Bit mask for definition of NCU global basic frames
$P_CHBFRMASK Bit mask for definition of channelspecific basic frames
$P_CHSFRMASK Bit mask for activating system frames in data management
$AA_ETRANS[X]
$AA_ETRANS[X] is an axisspecific system variable of the DOUBLE type. The default setting
in the system for this variable is zero. Values set by the user are activated by IS "Zero offset
external" (DB31-61, ... DBX3.0).
5.4 5.4 Signals
5.4.1 Signals from channel
DB number Byte.Bit Description
21, ... 61.0 T function modification
21, ... 62.0 D function modification
21, ... 118-119 T function
21, ... 129 D function
21, ... 208 Number of active function G group 1
21, ... 209 Number of active function G group 2
... ... ...
21, ... 230 Number of active function G group 29
