Detailed Description
2.4 Acceleration (B2)
NC/PLC Interface Signals (Z1)
Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
2-71
2.4 2. 4 Acceleration (B2)
No signal descriptions required.
2.5 2. 5 Diagnostic tools (D1)
No signal descriptions required.
2.6 2. 6 Travel to fixed stop (F1)
2.6.1 Signals to axis/spindle (DB31, ...)
DB31, ...
DBX1.1
Acknowledge fixed stop reached
Edge evaluation: no Signal(s) updated: cyclic
Signal state 1 or
edge change
0 → 1
Significance after the fixed stop has been reached:
DB31, ... DBX62.5 (fixed stop reached) = 1
→ The axis presses against the fixed stop with the clamping torque:
→ The fixed stop monitoring window is activated.
→ A block change is executed.
Signal state 0
Edge change
1 → 0
Significance after the fixed stop has been reached:
DB31, ... DBX62.5 (fixed stop reached) = 1
→ The axis presses against the fixed stop with the clamping torque.
→ The fixed stop monitoring window is activated.
→ A block change is not executed and the channel message
"Wait: Auxiliary function acknowledgment missing" is displayed.
Meaning after the fixed stop has been reached:
IS "Fixed stop reached" DB31, ... DBX62.5 = 1
→ The function is aborted, the alarm "20094 axis %1 Function aborted" is output.
Significance when de-selecting the function FXS=0 via the part program:
→ The torque limiting and the monitoring of the fixed stop monitoring window are canceled.
IS irrelevant
for ...
MD37060 $MA_FIXED_STOP_ACKN_MASK
(monitoring PLC acknowledgments for travel to fixed stop)
= 0 or 1
Corresponding to .... MD37060 $MA_FIXED_STOP_ACKN_MASK
(monitoring PLC acknowledgments for travel to fixed stop)
DB31, ... DBX62.5 (fixed stop reached)
