Detailed Description
2.3 Feedrate control
Feeds (V1)
2-24 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
2.3.2 Feedrate disable and feedrate/spindle stop
General
The feedrate disable or feedrate/spindle stop brings the axes to a standstill with adherence
to the braking characteristics and the path contour (exception: G33 block).
References:
/FB/ Description of Functions, Basic Machine; Continuous-Path Mode, Exact Stop and Look
Ahead (B1)
"Feedrate disable" DB21, ... DBX6.0
Interface signal "Feedrate disable" (DB21, ... DBX6.0) shuts down all axes (geometry and
auxiliary axes) of a channel in all modes.
Activation of channel-specific feedrate disable
If G33, G34, G35 active: Not effective
If G63 active: Effective
If G331, G332 active: Effective
"Feed stop" DB21, ...DBX12.3 geometry axes
Interface signals "Feed stop" (DB21, ... DBX12..3 and the following signals) for geometry
axes 1, 2, and 3 stop the geometry axes of a channel in JOG mode.
"Feed stop" DB31, ...DBX4.3 axis-specific
The axis-specific "Feed stop" interface signal (DB31, ... DBX4.3) is used to stop the relevant
machine axis.
In automatic mode:
• If the "Feed stop" is performed for a path axis, all the axes traversed in the current block
and all axes participating in the axis group are stopped.
• If the "Feed stop" is performed for a positioning axis, only this axis is stopped.
Only the current axis is stopped in JOG mode.
Activation of axis-specific function "Feed stop"
If G33, G34, G35 active: Effective
(causes contour deviations)
If G63 active: Effective
If G331, G332 active: Effective
