Data Lists

5.3 Signals

Spindles (S1)

5-4 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0

5.2.2 Axis/spindle-specific setting data

Number Identifier: $SA_ Description

43200 SPIND_S Specification of the spindle speed

43202 SPIND_CONSTCUT_S Specification of the constant cutting rate for the

master spindle

43210 SPIND_MIN_VELO_G25 Progr. Spindle speed limitation G25

43220 SPIND_MAX_VELO_G26 Progr. Spindle speed limitation G26

43230 SPIND_MAX_VELO_LIMS Progr. spindle speed limitation G96/G961

43240 M19_SPOS Spindle position for spindle positioning

with M19

43250 M19_SPOSMODE Spindle positioning approach mode for

spindle positioning with M19

43300 ASSIGN_FEED_PER_REF_SOURCE Rotational feedrate for positioning axes/spindles

5.3 5.3 Signals

5.3.1 Signals to axis/spindle

DB number Byte.Bit Description

31, ... 0 Feed override

31, ... 1.7 Override active

31, ... 1.6 Position measuring system 2

31, ... 1.5 Position measuring system 1

31, ... 1.4 Follow-up mode

31, ... 1.3 Axis/spindle disable

31, ... 2.2 Spindle reset/delete distance-to-go

31, ... 2.1 Servo enable

31, ... 3.6 Velocity/spindle speed limitation

31, ... 16.7 Delete S value

31, ... 16.5 Resynchronize spindle 2

31, ... 16.4 Resynchronize spindle 1

31, ... 16.3 Gear changed

31, ... 16.2-16.0 Actual gear step A to C

31, ... 17.6 Invert M3/M4

31, ... 17.5 Resynchronize spindle during positioning 2

31, ... 17.4 Resynchronize spindle during positioning 1

31, ... 18.7 Direction of rotation setpoint left
