5.2 Setting data
Mode Group, Channel, Program Operation, Reset Response (K1)
Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
5-7
5.1.2.7 Program runtime and workpiece counter
Number Identifier: $MC_ Description
27860 PROCESSTIMER_MODE Activate the runtime measurement
27880 PART_COUNTER Activate the workpiece counter
27882 PART_COUNTER_MCODE[ ] Workpiece counting via M command
5.1.3 Axis/spindlespecific machine data
Number Identifier: $MA_ Description
30550 AXCONF_ASSIGN_MASTER_CHAN Reset position of channel for axis change
30600 FIX_POINT_POS Fixed value positions of axes with G75
33100 COMPRESS_POS_TOL Maximum deviation with compensation
5.2 5.2 Setting data
5.2.1 Channelspecific setting data
Number Identifier: $SC_ Description
42000 THREAD_START_ANGLE Start angle for thread
42010 THREAD_RAMP_DISP Starting and deceleration distance of feed axis in
thread cutting
42100 DRY_RUN_FEED Dry run feedrate
42200 SINGLEBLOCK2_STOPRE Activate debug mode for SBL2
42444 TARGET_BLOCK_INCR_PROG Continuation mode after block search with calculation
42700 EXT_PROG_PATH Name of an external program path for subroutine call
EXTCALL
42750 ABSBLOCK_ENABLE Enable basic block display
42990 MAX_BLOCKS_IN_IPOBUFFER Control of max. number of blocks in interpolation
buffer
