5.2 Setting data
Tool Compensation (W1)
5-4 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
5.2 5.2 Setting data
5.2.1 Channel-specific setting data
Number Identifier: $SC_ Description
42442 TOOL_OFFSET_INCR_PROG Retraction of tool compensations on incremental
programming
42470 CRIT_SPLINE_ANGLE Corner limit angle for the compressor with COMPCAD
(changed in SW 7.1 and higher)
42480 STOP_CUTCOM_STOPRE Alarm response for tool radius compensation and
preprocessing stop
42494 CUTCOM_ACT_DEACT_CTRL Approach/retraction behavior for tool radius
compensation in blocks without travel information
42496 CUTCOM_CLSDT_CONT Maintain stability of approach/retraction behavior for
tool radius compensation in blocks
42900 MIRROR_TOOL_LENGTH Mirror tool length compensation
42910 MIRROR_TOOL_WEAR Mirror wear values of tool length compensation
42920 WEAR_SIGN_CUTPOS Mirror wear values of machining plane
42930 WEAR_SIGN Invert sign of all wear values
42935 WEAR_TRANSFORM Transformation of wear values
42940 TOOL_LENGTH_CONST Retain the assignment of tool length components
when changing the machining plane
(G17 to G19)
42950 TOOL_LENGTH_TYPE Assignment of the tool length components
independent of tool type
42960 TOOL_TEMP_COMP Temperature compensation value in relation to tool
42974 TCARR_FINE_CORRECTION Fine offset TCARR on/off
