Data Lists
5.1 Machine data
Axis Types, Coordinate Systems, Frames (K2)
5-2 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
Number Identifier: $MM_ Description
9449 WRITE_TOA_LIMIT_MASK Applicability of MD9203 to edge data
and locationdependent offsets
9450 9450 MM_WRITE_TOA_FINE_LIMIT Limit value for wear fine
9451 9451 MM_WRITE_ZOA_FINE_LIMIT Limit value for offset fine
9459 PA_ZOA_MODE Display mode of zero offset
5.1.2 NC-specific machine data
Number Identifier: $MN_ Description
10000 AXCONF_MACHAX_NAME_TAB Machine axis name
10600 FRAME_ANGLE_INPUT_MODE Input type for rotation with frame
10602 FRAME_GEOAX_CHANGE_MODE Frames and switchover of geometry axes
10610 MIRROR_REF_AX Reference axis for FRAME element mirroring
10612 MIRROR_TOGGLE Toggle mirroring
10613 NCBFRAME_RESET_MASK RESET response of global basic frame
10615 NCBFRAME_POWERON_MASK POWER ON response of global basic frames
10650 IPO_PARAM_NAME_TAB Name of interpolation parameters
10660 INTERMEDIATE_POINT_NAME_TAB Name of intermediate point coordinates for G2/G3
11640 ENABLE_CHAN_AX_GAP Channel axis gaps allowed
18600 MM_FRAME_FINE_TRANS Fine offset for all settable FRAMES and the basic
frame
18601 MM_NUM_GLOBAL_USER_FRAMES Number of globally predefined user frames
18602 MM_NUM_GLOBAL_BASE_FRAMES Number of global basic frames
5.1.3 Channel-specific machine data
Number Identifier: $MC_ Description
21015 INVOLUTE_RADIUS_DELTA NC start disable without reference point
20050 AXCONF_GEOAX_ASSIGN_TAB Assignment geometry axis to channel axis
20060 AXCONF_GEOAX_NAME_TAB Geometry axis name in channel
20070 AXCONF_MACHAX_USED Machine axis number valid in channel
20080 AXCONF_CHANAX_NAME_TAB Channel axis name/special axis name in channel
22532 GEOAX_CHANGE_M_CODE M code for replacement of geometry axes
22534 TRAFO_CHANGE_M_CODE M code for transformation changeover
