Detailed description
2.11 Supplementary conditions and NC VAR selector
Power Line Basic PLC Program (P3)
Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
2-77
Block size (bytes)
Block
type no.
Function
Remark
Load
memory
Working
memory
Maximum configuration (2 channels, 4 spindles, 4 axes, TMCP)
See above Basic program, base 14796 11720
See above Interface DBs 2542 2090
See above MCP 2300 1962
See above Error/status
messages
1572 1350
See above ASUBs 1 ASUB initiation 656 538
See above Concurrent axis For 2 turrets 674 560
See above PLC/NC
communication
1 x read variable and 1 x
write variable
8070 6388
See above Tool management 2 turrets with one
loading point each
3430 2854
See above Compile cycles 472 436
Total 34512 27898
2.11 2.11 Supplementary conditions and NC VAR selector
2.11.1 Supplementary conditions
2.11.1.1 Programming and parameterizing tools
Hardware
Programming devices or PCs with the following equipment are required for the PLCs
installed on the 810D and 840D:
