Detailed Description
2.4 Frames
Axis Types, Coordinate Systems, Frames (K2)
2-46 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
2.4.3.4 Scaling
\
[
6FDOLQJ
The program commands below are used to program the scaling:
$P_UIFR[1] = CSCALE(x, 1, y, 1)
SCALE x = 1 y = 1
$P_UIFR[1,x, sc] = 1
2.4.3.5 Mirroring
[
\
0LUURULQJ
