Detailed Description
2.10 Working with tool environments
Tool Compensation (W1)
2-138 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
Example 2
Machine data are to be used to define that compensation D2 and sum offset DL=1 are
activated on a tool change
(MD20270 $MC_CUTTING_EDGE_DEFAULT=2,
MD20272 $MC_SUMCORR_DEFAULT=1):
T5 M06 ; Tool number 5 is loaded - D2 + DL=1 are active
(= values of MD).
D1 DL=3 ; Compensation D1 + sum offset 3 of D1 are activated.
X10
DL=2 ; Compensation D1 + sum offset 2 are activated.
X20
DL=0 ; Sum offset deselection, only compensation D1 is now active.
D2 ; Compensation D2 is activated - sum offset DL=1 is activated.
X1
DL=2 ; Compensation D2 + sum offset 2 are activated.
D1 ; Compensation D1 + sum offset 1 are activated.
2.9.5 Upgrades for Tool Length Determination
2.10 2.10 Working with tool environments
2.10.1 General
Functions
The current states of tool data can be processed using the functions below, which are
generally available:
• Save
• Deletion
• Read
• Modify
A further function can be used to determine information about the assignment of the tool
lengths of the active tool to the abscissa, ordinate and applicate.
