Data Lists
5.3 Signals
Mode Group, Channel, Program Operation, Reset Response (K1)
Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
5-9
DB number Byte.Bit Description
11, ... 7.0 Active machine function TEACH-IN
11, ... 7.1 Active machine function REPOS
11, ... 7.2 Active machine function REF
5.3.4 Signals to channel
DB number Byte.Bit Description
21, ... 0.3 Activate DRF
21, ... 0.4 Activate single block
21, ... 0.5 Activate M01
21, ... 0.6 Activate dry run feed
21, ... 1.0 Activate referencing
21, ... 1.6 PLC action ended
21, ... 1.7 Activate program test
21, ... 2.0 – 2.7 Skip-block levels: /0 to /7
21, ... 7.0 NC Start disable
21, ... 7.1 NC Start
21, ... 7.2 NC Stop at block limit
21, ... 7.3 NC stop
21, ... 7.4 NC Stop axes plus spindles
21, ... 7.7 Reset
21, ... 31.0 - 31.2 REPOSPATHMODE
21, ... 31.4 REPOSMODEEDGE
5.3.5 Signals from channel
DB number Byte.Bit Description
21, ... 24.3 DRF selected
21, ... 24.4 Select associated M01
21, ... 24.5 M01 selected
21, ... 24.6 Dry run feedrate selected
21, ... 25.3 Feedrate override selected for rapid traverse
21, ... 25.7 Program test selected
21, ... 26.0 – 26.7 Skip-block selected: /0 - /7
21, ... 27.0 Skip-block selected
21, ... 27.1 Skip-block selected
21, ... 31.6 Skip-block active /8
21, ... 31.7 Skip-block active /9
