Data Lists
5.1 Machine data
Mode Group, Channel, Program Operation, Reset Response (K1)
5-2 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
Number Identifier: $MN_ Description
11450 SEARCH_RUN_MODE Block search parameter settings
11470 REPOS_MODE_MASK Repositioning properties
11600 BAG_MASK Mode group response to ASUB
11602 ASUP_START_MASK Ignore stop conditions for ASUB
11604 ASUP_START_PRIO_LEVEL Priorities for "ASUP_START_MASK effective"
11610 ASUP_EDITABLE Activation of a user ASUB for RET/REPOS
11612 ASUP_EDIT_PROTECTION_LEVEL Protection level of user-specific ASUB
11620 PROG_EVENT_NAME Program name for PROG-EVENT
11717 D_NO_FCT_CYCLE_NAME Subroutine name for D function replacement
15700 LANG_SUB_NAME Name for replacement subroutine
15702 LANG_SUB_PATH Call path for replacement subroutine
17200 GMMC_INFO_NO_UNIT Global HMI info (without physical unit)
17201 GMMC_INFO_NO_UNIT_STATUS Global HMI status info (without physical unit)
18360 MM_EXT_PROG_BUFFER_SIZE FIFO buffer size for one program level
18362 MM_EXT_PROG_NUM Number of external program levels (DRAM)
5.1.2 Channel-specific machine data
5.1.2.1 Basic machine data
Number Identifier: $MC_ Description
20000 CHAN_NAME Channel name
20050 AXCONF_GEOAX_ASSIGN_TAB Assignment of geometry axis to channel axis
20060 AXCONF_GEOAX_NAME_TAB Geometry axis name in channel
20070 AXCONF_MACHAX_USED Machine axis number valid in channel
20080 AXCONF_CHANAX_NAME_TAB Channel axis name in channel [channel axis no.]: 0...7
20090 SPIND_DEF_MASTER_SPIND Initial setting of master spindle in channel
20100 DIAMETER_AX_DEF Geometry axis with transverse axis function
20106 PROG_EVENT_IGN_SINGLEBLOCK Prog events ignore the single block
20107 PROG_EVENT_IGN_INHIBIT Prog events ignore the read-in disable
20108 PROG_EVENT_MASK Eventdriven program calls
20109 PROG_EVENT_MASK_PROPERTIES Prog events properties
20114 MODESWITCH_MASK Setting for REPOS
20116 IGNORE_INHIBIT_ASUP Execute user ASUBs completely in spite of readin
disable
20117 IGNORE_SINGLEBLOCK_ASUP Process user ASUBs completely in spite of single-
block processing
20160 CUBIC_SPLINE_BLOCKS Number of blocks for C spline
