2.1 Tool
Tool Compensation (W1)
2-16 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
The following occurs when this part of the program is executed again:
Txx ; Error! Data set with xx does not exist,
; Detect state; detect xx;
; continue in program
....
Tyy M06 ; Detect bit memory "xx missing" → cancel without further
response,
; as Tyy M06 is correct → program does not stop (correct).
If necessary, the original point of the T call can be corrected after the end of the program. If
the tool change logic on the machine cannot process this, the program must be aborted and
the point of the error corrected.
If only one data set is missing, it is transferred to the NCK, Txx is programmed in "Overstore"
and the program is subsequently resumed.
As in the case of "missing D number", the required parameter (T number) can be accessed
by the user for "missing T number" via the appropriate alarm (17191).
Note
During program testing, the program also stops immediately at the Txx block containing the
error if MD22562 $MC_TOOL_CHANGE_ERROR_MODE bit0=1,
to allow the program to be corrected.
2.1.7 Definition of the effect of the tool parameters
MD20360
Machine data:
MD20360 $MC_TOOL_PARAMETER_DEF_MASK
can control the effect of the tool parameters on the transverse axis in connection with
diameter programming. Details are described with the mentioned MD.
DRF handwheel traversal with half distance
During DRF handwheel traversal, it is possible to move a transverse axis through only half
the distance of the specified increment as follows:
Specify the distance with handwheel via:
MD11346 $MN_HANDWHEEL_TRUE_DISTANCE = 1
