5.2 Signals
Reference Point Approach (R1)
5-4 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
5.2.5 Signals to axis
DB number Byte.Bit Name
31, ... 1.4 Follow-up mode (request)
31, ... 1.5/1.6 Position measuring system 1/position measuring system 2
31, ... 2.4 - 2.7 Reference point value 1 to 4
31, ... 4.6/4.7 Traversing keys minus/plus
31, ... 12.7 Decelertion of reference point approach
5.2.6 Signals from axis
DB number Byte.Bit Name
31, ... 60.4/60.5 Referenced, synchronized 1/Referenced, synchronized 2
31, ... 61.3 Follow-up mode active
31, ... 64.6/64.7 Traverse command minus/plus
