Detailed description
2.9 Assignment overview
Power Line Basic PLC Program (P3)
2-72 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
ManualTurn
ManualTurn uses FC 30 to 35 and DB 81 to 89.
ManualTurn is an operating system for conventional, cyclecontrolled turning machines. The
above FCs and DBs can be used provided that the machine to be configured is not a turning
machine with a maximum of two axes and one spindle. If your machine is of this type and if
you might require conventional operating methods in addition to CNC functions, then you
should not use the FCs and DBs above.
ShopMill
ShopMill uses FC30 to 35 and DB 81 to 89.
ShopMill is an operating system for 2 1/2D milling machines in the workshop environment.
The above FCs and DBs can be used provided that the machine to be configured is not a
milling machine for 2 1/2D machining operations. However, if you intend to use your machine
for applications of this type, then the FCs and DBs should not be used.
2.9.3 Assignment: DB
Note
Only as many data blocks as are required according to the NC machine data configuration
are set up.
Overview of data blocks
DB no. Designation Name Package
1 Reserved for Siemens BP
4 PLC-MELD PLC messages BP
8 Reserved for Siemens
9 NC-COMPILE Interface for NC compile cycles BP
10 NC INTERFACE Central NC interface BP
11 Mode group 1 Interface mode group BP
12 Computer link and transport system interface
14 Reserved for Siemens
15 Basic program
16 PI Service definition
17 Version ID
18 Reserved for basic program
