5.1 Machine data
Tool Compensation (W1)
5-2 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
5.1.2 Channel-specific machine data
Number Identifier: $MC_ Description
20096 T_M_ADDRESS_EXT_IS_SPINO Spindle number as address extension
20110 RESET_MODE_MASK Definition of control basic setting after power-up and
RESET parts program end
20120 TOOL_RESET_VALUE Definition of tool, for which tool length compensation
is selected during power-up or on reset or parts
program end as a function of machine data:
MD20110 RESET_MODE-MASK.
20121 TOOL_PRESEL_RESET_VALUE Definition of the preselected tool, for which the tool
length compensation is selected during power-up and
on reset or parts program end as a function of
MD20110.
20126 TOOL_CARRIER_RESET_VALUE Active toolholder on RESET
20130 CUTTING_EDGE_RESET_VALUE Definition of tool cutting edge, for which tool length
compensation is selected during power-up or on reset
or parts program end as a function of machine data:
MD20110 RESET_MODE-MASK.
20132 SUMCORR_RESET_VALUE Number for selecting sum offset
20140 TRAFO_RESET_VALUE Definition of transformation set, which is selected
during power-up or on reset or parts program end as
a function of machine data:
MD20110 RESET_MODE-MASK.
20180 TOCARR_ROT_ANGLE_INCR[i] Value of the minimum incremental step with toolholder
with orientation capability
20182 TOCARR_ROT_ANGLE_OFFSET[i] Offset of the rotary axis with toolholder with
orientation capability
20184 TOCARR_BASE_FRAME_NUMBER Base frame of the table offset for toolholder with
orientation capability with rotary table
20188 TOCARR_FINE_LIM_LIN Limit linear fine offset TCARR
20190 TOCARR_FINE_LIM_ROT Limit rotary fine offset TCARR
20202 WAB_MAXNUM_DUMMY_BLOCKS Maximum number of blocks with no traversing
motions with SAR
20204 WAB_CLEARANCE_TOLERANCE
20210 CUTCOM_CORNER_LIMIT Max. angle for intersection calculation with tool radius
compensation
20220 CUTCOM_MAX_DISC Maximum value for tool radius compensation
20230 CUTCOM_CURVE_INSERT_LIMIT Minimum value for intersection calculation with tool
radius compensation
20240 CUTCOM_MAXNUM_CHECK_BLOCKS Blocks for predictive contour calculation with tool
radius compensation
20250 CUTCOM_MAXNUM_DUMMY_BLOCKS Max. no. of dummy blocks with no traversing
movements
20252 CUTCOM_MAXNUM_SUPPR_BLOCKS Maximum number of blocks with compensation
suppression
