Detailed Description
2.5 Programming
Spindles (S1)
2-72 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
Bit 5 = 1 The content of setting data:
SD43200 $SA_SPIND_S
serves as the setpoint speed in JOG mode.
You can use the JOG keys to operate the spindle at the speed defined in
SD43200.
If the content is zero, other JOG speed specifications are active
(see setting data SD41200 $SN_JOGSPIND_SET_VELO).
Bit 8 = 1 The programmed cutting speed including specifications for FC18 and
synchronized actions are accepted in SD43202 $SA_SPIND_S.
Spindle override is also actively influenced during zero marker search with M19, SPOS, or SPOSA.
Bit 12 = 1 Spindle override is effective during zero marker search with M19, SPOS, or
SPOSA.
For additional information about machine data:
MD35035 $MA_SPIND_FUNCTION_MASK
please refer to:
References:
/FB1/ Descriptions of Functions, Basic Machine; Acceleration (B2)
2.5.5 Gear step change with DryRun, program testing and SERUPRO
Part program, synchronized actions and FC18
The behavior of the gear step change from the part program, FC18 and synchronized
actions for the DryRun, program testing and SERUPRO (SearchRunByProgramtest)
functions can be configured using the existing machine data:
MD35035 $MA_SPIND_FUNCTION_MASK.
These functions do not generally require a gear step change and can therefore be
suppressed in machine data:
MD35035 $MA_SPIND_FUNCTION_MASK
with bits 0 to 2 as follows:
Dry run feedrate (DryRun)
Bit 0 = 0 Gear steps are activated even with the DryRun function active for part program
blocks with M40, M41 to M45 or via FC18 and synchronized action programming
(response).
Bit 0 = 1 Gear step change for blocks with M40, M41 to M45 or via FC18 and synchronized
actions are suppressed with DryRun.
Program testing and SERUPRO
Bit 1 = 0 Gear steps are activated even with the Program Test function active for part
program blocks with M40, M41 to M45 or via FC18 and synchronized action
programming (response).
Bit 1 = 1 Gear step change for blocks with M40, M41 to M45 or via FC18 and synchronized
actions are suppressed with Program Test and SERUPRO.
