Detailed Description
2.2 Axis monitoring, protection zones (A3)
NC/PLC Interface Signals (Z1)
Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
2-65
DB21, ...
DBX10.0 - DBX11.1
Activate channel-specific protection zone 1 ( ...10)
Edge evaluation: no Signal(s) updated: cyclic
Signal state 1 or
edge change
0 → 1
The pre-activated, channel-specific protection zone 1 ( ...10) is activated by the PLC user program.
The protection zone is immediately active.
Only protection zones that have been pre-activated in the part program can be activated.
Signal state 0 or
edge change
1 → 0
The pre-activated, channel-specific protection zone 1 ( ...10) is de-activated by the PLC user
program.
The protection zone is immediately de-activated.
Only protection zones that have been activated via the PLC and have been pre-activated in the NC
part program can be de-activated.
Application
example(s)
Before a synchronous spindle, for example, is moved into the working range, the relevant machine-
related protection zone can be activated.
2.2.2 Signals from channel (DB21, ...)
DB21, ...
DBX272.0 –
DBX273.1
Machine-related protection zone 1 ( ...10) pre-activated
Edge evaluation: no Signal(s) updated: cyclic
Signal state 1 or
edge change
0 → 1
The machine-related protection zone 1 ( ...10) is preactivated in the current block.
(Pre-activated in the part program).
The protection zone can therefore be activated or de-activated in the PLC user program using the
interface signal:
DB21, ... DBX8.0 - DBX9.1 (machine-related protection zone 1 (...10))
Signal state 0 or
edge change
1 → 0
The machine-related protection zone 1 (...10) is deactivated in the current block.
(De-activated in the part program).
The protection zone can therefore not be activated or de-activated in the PLC user program using
the interface signal:
DB21, ... DBX8.0 to DBX9.1 (activate machine-related protection zone 1 (...10))
Corresponding
to ....
DB21, ... DBX8.0 - DBX9.1 (activate machine-related protection zone 1 (...10))
DB21, ...
DBX274.0 –
DBX275.1
Channel-specific protection zone 1 (...10) pre-activated
Edge evaluation: no Signal(s) updated: cyclic
Signal state 1 or
edge change
0 → 1
The channel-specific protection zone 1 ( ...10) is preactivated in the current block.
(Pre-activated in the part program).
The protection zone can therefore be activated or de-activated in the PLC user program using the
interface signal:
DB21, ... DBX10.0 - DBX11.1 channel-specific protection zone 1 (...10))
