Data Lists
5.1 Machine data
Mode Group, Channel, Program Operation, Reset Response (K1)
5-6 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
Number Identifier: $MC_ Description
24560 TRAFO5_JOINT_OFFSET_1 Vector of kinematic offset for 5-axis transformation 1
24600 TRAFO5_PART_OFFSET_2 Offset vector of 5-axis transformation 2
24610 TRAFO5_ROT_AX_OFFSET_2 Position offset of rotary axes 1/2 for 5axis
transformation 2
24620 TRAFO5_ROT_SIGN_IS_PLUS_2 Sign of rotary axis 1/2 for 5axis transformation 2
24630 TRAFO5_NON_POLE_LIMIT_2 Definition of pole limit for 5-axis transformation 2
24640 TRAFO5_POLE_LIMIT_2 Pole end angle tolerance for interpolation for 5axis
transformation 2
24650 TRAFO5_BASE_TOOL_2 Vector of base tool on activation of 5-axis
transformation 2
24660 TRAFO5_JOINT_OFFSET_2 Vector of kinematic offset for 5-axis transformation 2
5.1.2.6 Memory settings
Number Identifier: $MC_ Description
25000 REORG_LOG_LIMIT Percentage of IPO buffer for log file enable
28000 MM_REORG_LOG_FILE_MEM Memory size for REORG (DRAM)
28010 MM_NUM_REORG_LUD_MODULES Number of blocks for local user variables for REORG
(DRAM)
28020 MM_NUM_LUD_NAMES_TOTAL Number of local user variables (DRAM)
28030 MM_NUM_LUD_NAMES_PER_PROG Number of local user variables per program (DRAM)
28040 MM_LUD_VALUES_MEM
(available soon)
Memory size for local user variables (DRAM)
28050 MM_NUM_R_PARAM Number of channelspecific R parameters (SRAM)
28060 MM_IPO_BUFFER_SIZE Number of NC blocks in IPO buffer (DRAM)
28070 MM_NUM_BLOCKS_IN_PREP
(available soon)
Number of blocks for block preparation (DRAM)
28080 MM_NUM_USER_FRAMES Number of settable Frames (SRAM)
28090 MM_NUM_CC_BLOCK_ELEMENTS Number of block elements for compile cycles (DRAM)
28100 MM_NUM_CC_BLOCK_USER_MEM Size of block memory for compile cycles (DRAM)
28400 MM_ABSBLOCK Dimension basic block display
28402 MM_ABSBLOCK_BUFFER[2] Dimension size of upload buffer
28500 MM_PREP_TASK_STACK_SIZE Stack size of preparation task (DRAM)
28510 MM_IPO_TASK_STACK_SIZE Stack size of IPO task (DRAM)
