Detailed Description
2.3 Starting up hardware configuration of PLC CPUs
PLC Basic Program Solution Line (P3 sl)
Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
2-7
2.3 2.3 Starting up hardware configuration of PLC CPUs
General procedure
The hardware configuration for the PLC CPUs used in the NCU7x0, including other
components of the NCU (NCK, CP, HMI, drive), must be defined via STEP 7.
Proceed as follows in STEP7:
1. Create a new project (File, New, Project)
2. Insert, Hardware, SIMATIC 300 station
3. Select the SIMATIC 300 station with the mouse
4. Right-click with the mouse and select Open Object
and start HWConfig
5. A suitable SINUMERIK component is selected from the "SIMATIC 300\SINUMERIK\840D
sl" hardware catalog.
6. Add I/O from the STEP7 hardware catalog
The addresses for the I/O modules can be modified if required.
Requirements
In order to be able to select SINUMERIK components from the hardware catalog, you must
run the Toolbox setup program first ("Hardware expansions for STEP7" and "Starter"). The
current version of the hardware expansion for STEP7 can also be found under eSupport.
Table 2-1 Hardware expansions
NCU
MLFB
Comparable
SIMATIC CPU MLFB
included
Selection from STEP7 hardware
catalog
SINUMERIK 840D NCU
710.1
6FC5 371-0AA00-?AA0 6ES7 317-2AJ00-0AB0 NCU710.1
(as of STEP7 V5.3 SP2
and Toolbox 840D sl 01.01.00)
SINUMERIK 840D NCU
720.1
6FC5 372-0AA00-?AA0 6ES7 317-2AJ00-0AB0 NCU720.1
(as of STEP7 V5.3 SP2
and Toolbox 840D sl 01.01.00)
SINUMERIK 840D NCU
730.1
6FC5 373-0AA00-?AA0 6ES7 317-2AJ00-0AB0 NCU730.1
(as of STEP7 V5.3 SP2
and Toolbox 840D sl 01.01.00)
SINUMERIK 840Di sl with
MCI2
6FC5 222-0AA02-1AA0
6ES7 317-2AJ00-0AB0
840Di with PLC317-2 DP
(as of STEP7 V5.3 SP2
and Toolbox 840D sl 01.02.00)
