Detailed Description
2.7 Program operation mode
Mode Group, Channel, Program Operation, Reset Response (K1)
2-102 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
NCK events Response Stop criteria
STOPPROGATASUPEND System fault SR end should always deselect the stop delay section.
WAITM Alarm 16954 NC prog.: WAITM
WAITE Alarm 16954 NC prog.: WAITE
INIT_SYNC Alarm 16954 NC prog.: INIT with parameter "S"
MMCCMD Alarm 16954 NC prog.: MMC( STRING, CHAR )
PROGMODESLASHON delayed IS: DB21, ... DBB26 Activate/switch over skip block
PROGMODESLASHOFF delayed IS: DB21, ... DBB26 deactivate skip block
PROGMODEDRYRUNON delayed IS: DB21, ... DBX0.6 Activate DryRun
PROGMODEDRYRUNOFF delayed IS: DB21, ... DBX0.6 Deactivate DryRun
BLOCKREADINHIBIT_ON delayed IS: DB21, ... DBX6.1 Activate read-in disable
STOPATEND_ALARM immediate Alarm: Alarm configuration STOPATENDBYALARM
STOP_ALARM immediate Alarm: Alarm configuration STOPBYALARM
STOPATIPOBUFFER_ISEMPTY_
ALARM
immediate Internal: Stop after alarm on empty IPO buffer
STOPATIPOBUF_EMPTY_ALARM_
REORG
immediate Internal: Stop after alarm on empty IPO buffer
RETREAT_MOVE_THREAD Alarm 16954 NC prog.: Alarm 16954 with LFON (stop and fastlift in G33
not possible)
WAITMC Alarm 16954 NC prog.: WAITMC
NEWCONF_PREP_STOP Alarm 16954 NC prog.: NEWCONF
BLOCKSEARCHRUN_NEWCONF Alarm 16954 NC prog.: NEWCONF
SET_USER_DATA delayed OPI: PI "_N_SETUDT"
SYSTEM_SHUTDOWN immediate System shutdown for SINUMERIK 840Di
ESR delayed Extended stop and retract
EXT_ZERO_POINT delayed External work offset
STOPRUN Alarm 16955 OPI: PI "_N_FINDST" STOPRUN
2.7.13 Asynchronous Subroutines (ASUBs), Interrupt Routines
Overview
Interrupt inputs allow the NC to interrupt the current NC processing operation so that it can
react to more urgent events in interrupt routines or ASUBs.
