5.1 Machine data
Mode Group, Channel, Program Operation, Reset Response (K1)
5-4 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
5.1.2.3 Reset response
Number Identifier: $MC_ Description
20110 RESET_MODE_MASK Initial setting at RESET
20112 START_MODE_MASK Initial setting at special NC Start after power-up and at
RESET
20118 GEOAX_CHANGE_RESET Allow automatic geometry axis change
20120 TOOL_RESET_VALUE Tool whose length compensation is selected during
powerup (Reset/part program end)
20121 TOOL_PRESEL_RESET_VALUE Preselected tool whose length compensation is
selected in powerup (Reset/part program end)
20130 CUTTING_EDGE_RESET_VALUE Tool cutting edge on power-up (Reset/part program
end)
20140 TRAFO_RESET_VALUE Active transformation on RESET
20150 GCODE_RESET_VALUES Reset G groups
20152 GCODE_RESET_MODE G code basic setting at RESET
20156 MAXNUM_GCODES_EXT Reset behavior of the external G groups
22620 START_MODE_MASK_PRT Initial setting at special NC Start after power-up and at
RESET
5.1.2.4 Auxiliary function settings
Number Identifier: $MC_ Description
22000 AUXFU_ASSIGN_GROUP Auxiliary function group
22010 AUXFU_ASSIGN_TYPE Auxiliary function type
22020 AUXFU_ASSIGN_EXTENSION Auxiliary function extension
22030 AUXFU_ASSIGN_VALUE Auxiliary function value
22200 AUXFU_M_SYNC_TYPE Output timing of M functions
22210 AUXFU_S_SYNC_TYPE Output timing of S functions
22220 AUXFU_T_SYNC_TYPE Output timing of T functions
22230 AUXFU_H_SYNC_TYPE Output timing of H functions
22240 AUXFU_F_SYNC_TYPE Output timing of F functions
22250 AUXFU_D_SYNC_TYPE Output timing of D functions
22260 AUXFU_E_SYNC_TYPE (available soon) Output timing of E functions.
22300 AUXFU_AT_BLOCK_SEARCH_END Output of auxiliary functions after block search
22400 S_VALUES_ACTIVE_AFTER_RESET S function active after RESET
22410 F_VALUES_ACTIVE_AFTER_RESET F function active after reset
22500 GCODE_OUTPUT_TO_PLC G functions to PLC
22510 GCODE_GROUPS_TO_PLC G codes that are output to the NCK/PLC interface on
block change/RESET
22550 TOOL_CHANGE_MODE New tool offset for M function
22560 TOOL_CHANGE_M_CODE M function for tool change
