2.7 Program operation mode
Mode Group, Channel, Program Operation, Reset Response (K1)
Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
2-87
2.7.7 Responses to operator or program actions
Status transitions
The following table shows the channel and program statuses that result after certain operator
and program actions.
The lefthand side of the table lists the channel and program statuses as well as the operating
modes from which the starting situation must be can be selected. Various operator/program
actions are listed on the righthand side of the table, the number of the situation after the
action has been carried out is shown in brackets after each action.
Table 2-3 Responses to operator or program actions
Situation Channel
status
Program status Active mode Operator or program action (situation after the
action)
R V A N V S W A A M J
1 x x x RESET (4)
2 x x x RESET (5)
3 x x x RESET (6)
4 x x x NC Start (13); Mode change (5 or 6)
5 x x x NC Start (14); Mode change (4 or 6)
6 x x x Direction key (15); Mode change (4 or 5)
7 x x x NC Start (14)
8 x x x NC Start (15)
9 x x x NC Start (13); Mode change (10 or 11)
10 x x x NC Start (16); Mode change (9 or 11)
11 x x x Direction key (17); Mode change (9 or 10)
12 x x x NC Start (13); Mode change (10 or 11)
13 x x x NC Stop (12)
14 x x x NC Stop (7); at block end (5)
15 x x x NC Stop (8); at JOG end (6)
16 x x x NC Stop (10); at block end (10)
17 x x x NC Stop (11); at JOG end (11)
18 x x x Reset (4); wait for other channel (18)
Channel status Program status Operating modes
R --> aborted N --> aborted A --> aborted
U --> interrupted U --> interrupted M --> aborted
A --> running S --> stopped J --> aborted
W --> waiting
A --> running
