Detailed Description
2.1 Various interface signals and functions (A2)
NC/PLC Interface Signals (Z1)
2-10 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
DB19
DBX0.7 Actual value in WCS
Corresponding to .... DB19, DBX20.7 (change over MCS/WCS)
Additional references /BA/ Operator's Guide
DB19
DBW2 Higraph first error display
Edge evaluation: no Signal(s) updated: cyclic
DB19
DBW4 Higraph first error display
Edge evaluation: no Signal(s) updated: cyclic
DB19
DBX6.0...7 Analog spindle 1, utilization in percent
Edge evaluation: no Signal(s) updated: cyclic
DB19
DBX7.0 - DBX7.7 Analog spindle 2, utilization in percent
Edge evaluation: no Signal(s) updated: cyclic
DB19
DBX8.0 - DBX8.7 Channel number of the machine control panel on the MMC
Edge evaluation: no Signal(s) updated: cyclic
DB19
DBX10.0 Programming area selection
Edge evaluation: no Signal(s) updated: cyclic
Signal state 1 or
edge change 0 → 1
Program area selection active
Signal state 0 or
edge change 1 → 0
Program area selection inactive
