Detailed Description
2.1 Various interface signals and functions (A2)
NC/PLC Interface Signals (Z1)
2-24 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
DB19
DBX27.0 - DBX27.7 Data transfer error
Edge evaluation: no Signal(s) updated: cyclic
Meaning
• 0 = no error
• 1 = invalid number for control file
(value in DB19.DBB16<127 or invalid)
• 2 = DB19.DBB17 could not be read
• 3 = control file /BD.DIR/PLC_IN_OUT_xxx.TEA not found
(value in DB19.DBB16 invalid)
• 4 = invalid index in control file
(value in DB19.DBB17 incorrect)
• 5 = selected job list in control file could not be opened
• 6 = error in the job list (job list interpreter signals an error)
• 7 = job list interpreter signals an empty job list
• 8 = data transfer error
The error text is entered into the DIENSTE PROTOKOLL [SERVICES REPORT].
• 9 = error while executing the job list
Corresponding to .... Valid for HMI Advanced
DB19
DBX40.0 - DBX40.7 Mode group number
Edge evaluation: no Signal(s) updated: cyclic
Meaning This byte contains the mode group number.
DB19
DBX41.0 - DBX41.7 Channel number (FC9: ChanNo)
Edge evaluation: no Signal(s) updated: cyclic
Meaning This byte contains the channel number (FC9: ChanNo).
DB19
DBX42.0 FC9: Start (measuring in Jog mode)
Edge evaluation: no Signal(s) updated: cyclic
Signal state 1 or
edge change 0 → 1
Start active
Signal state 0 or
edge change 1 → 0
Start inactive
