Detailed Description
2.1 Various interface signals and functions (A2)
NC/PLC Interface Signals (Z1)
2-46 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
DB31, ...
DBX76.0
Lubrication pulse
Edge evaluation: yes Signal(s) updated: when a change is made
Signal state 1 or
edge change
0 → 1
If the axis has traversed a distance further than entered in the machine data:
MD33050 $MA_LUBRICATION_DIST (travel distance for lubrication from the PLC)
then the interface signal:
DB31, ...DBX76.0 (lubrication pulse)
is set for one PLC cycle.
Signal state 0 or
edge change
1 → 0
IS "Lubrication pulse" is automatically reset to 0 after one PLC cycle.
Application
example(s)
The lubrication pump for the axis can be activated with IS "Lubrication pulse".
Machine bed lubrication therefore depends on the distance traveled.
Corresponding to .... MD33050 $MA_LUBRICATION_DIST (lubrication pulse distance)
DB31, ...
DBX92.0
Setting-up mode active
Edge evaluation: no Signal(s) updated: cyclic
Signal state 1 or
edge change
0 → 1
Setting-up mode is active for the drive (611D). The setting-up mode is selected using the terminals
on the infeed/regenerative feedback module.
The setting-up mode is required for optimizing the machining process.
The following adaptations and additional functions are possible:
• Drive:
– Reducing the speed setpoint limits
– Reducing the current setpoint limits
• I/RF:
– Disabling the closed-loop DC link voltage control
Signal state 0 or
edge change
1 → 0
Normal operation is active for the drive. The following thus applies:
• The maximum limit values for speed and current setpoint are active
• DC link voltage control is active
Signal irrelevant
for ...
SINUMERIK 840Di, 810D
Additional references /IAD/ SINUMERIK 840D Installation and Startup Guide; Chapter: SIMODRIVE 611D
DB31, ...
DBX92.1
Ramp-function generator fast stop active
Edge evaluation: no Signal(s) updated: cyclic
Signal state 1 or
edge change
0 → 1
PLC receives the signal that the ramp function generator fast stop is active.
The function has been activated by the interface signal:
DB31, ... DBX20.1 (ramp-function generator fast stop)
The drive is stopped without a ramp function with speed setpoint = 0 and without pulse
suppression.
