Detailed Description
2.9 Mode group, channel, program operation, reset response (K1)
NC/PLC Interface Signals (Z1)
Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
2-89
DB11, ...
DBX6.7
All channels in the reset state
Edge evaluation: no Signal(s) updated: cyclic
Signal state 1 or
edge change
0 → 1
All the channels that belong to this mode group are in the "channel status reset" state
(DB21, ... DBX7.7).
Signal state 0 or
edge change
1 → 0
At least one of the channels in the mode group is not in "channel status reset" (DB21, ... DBX7.7).
Corresponding to .... DB21, ... DBX7.7 (channel state, reset)
DB11, ...
DBX7.0
Active machine function TEACH IN
Edge evaluation: no Signal(s) updated: cyclic
Signal state 1 or
edge change
0 → 1
Machine function TEACH IN is active in the mode group.
Signal state 0 or
edge change
1 → 0
Machine function TEACH IN is not active.
Additional references /BA/ Operator's Guide
DB11, ...
DBX7.1
Active REPOS machine function
Edge evaluation: no Signal(s) updated: cyclic
Signal state 1 or
edge change
0 → 1
Machine function REPOS is active in the mode group.
Signal state 0 or
edge change
1 → 0
Machine function REPOS is not active.
Application
example(s)
When a fault occurs when executing a part program (e.g. tool breakage), the axis is manually
moved away from the fault location in the JOG mode in order to be able to replace the tool.
The axis can then be manually returned to the exact previous position using the REPOS machine
function so that the program can be continued in the automatic mode.
Further references /BA/ Operator's Guide
