Detailed Description
2.9 Mode group, channel, program operation, reset response (K1)
NC/PLC Interface Signals (Z1)
2-100 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
DB21, ...
DBX33.5
M02/M30 active
Special cases,
errors, ......
• The M02 and M30 functions have equal priority.
• The interface signal:
DB21, ... DBX33.5 (M02/M30 active)
is available as steady-state signal after the end of the program.
• Not suitable for automatic follow-on functions such as workpiece counting, bar feed, etc.
M02/M30 must be written in a separate block and the word M02/M30 or the decoded M signal
used for these functions.
• Auxiliary functions that could result in a read-in operation being stopped and any S values that
are to be operative beyond M02/M30 must not be written in the last block of a program.
DB21, ...
DBX33.6
Transformation active
Edge evaluation: no Signal(s) updated: cyclic
Signal state 1 or
edge change
0 → 1
The NC command TRAORI (activate transformation) is programmed in the NC part program. This
block has been processed by the NC and the transformation is now activated.
Signal state 0 or
edge change
1 → 0
No transformation active.
Additional references /PA/ Programming Guide Fundamentals
DB21, ...
DBX33.7
Program test active
Edge evaluation: no Signal(s) updated: cyclic
Signal state 1 or
edge change
0 → 1
Program control program test is active. Axis disable is set internally for all axes (not spindles).
Therefore the machine axes do not move when a part program block or a part program is being
processed. The axis movements are simulated on the operator interface with changing axis position
values.
The axis position values for the display are generated from the calculated setpoints.
The part program is processed in the normal way.
Signal state 0 or
edge change
1 → 0
Program control "Program test" is not active.
Corresponds to .... DB21, ... DBX1.7 (activate program test)
DB21, ... DBX25.7 (program test selected)
