Detailed Description
2.9 Mode group, channel, program operation, reset response (K1)
NC/PLC Interface Signals (Z1)
Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
2-105
DB21, ...
DBX37.7
Stop at block end is ignored during single block (SBL)
Signal state 1 Single block is active (DB21, ... DBX0.4==1) AND part program block is single block-inoperative.
Signal state 0 Single block is not active (DB21, ... DBB0.4 == 0) OR
(single block is active (DB21, ... DBX0.4 == 1) AND part program block is single block-operative)
Corresponds to .... Read-in disable is ignored. DB21, ... DBX37.6 (read-in disable is ignored)
DB21, ...
DBB208 - DBB271
Active G function of groups 1 to 60
Edge evaluation: no Signal(s) updated: cyclic
Signal state <> 0 A G function or mnemonic identifier of the G group is active.
The active G function can be determined from the value (starting with 1):
1 = First G function of the G group
2 = Second G function of the G group
3 = Third G function of the G group
:
Please refer to the programming guide for a list of the possible G groups and associated functions.
Signal state = 0 No G function or G group mnemonic identifier is active.
Application
example(s)
The active G group is stored in binary code in the relevant byte.
The following evaluation applies:
%LW
(YDOXDWLRQ
([DPSOH
*
Special cases,
errors, ......
In contrast to auxiliary functions, G functions are not output to the PLC subject to
acknowledgement, i.e., processing of the part program is continued immediately after the
G function output.
Additional references /PA/ Programming Guide Fundamentals
DB21, ...
DBX318.0
ASUB is stopped
Edge evaluation: no Signal(s) updated: cyclic
Signal state 1 or
edge change
0 → 1
The signal is set to 1 if the control stops automatically prior to the end of the ASUB.
The IS "ASUB is stopped" is only supplied in the case "Interrupt in a program mode and channel
status stopped".
Signal state 0 or
edge change
1 → 0
The IS "ASUB is stopped" is set to 0 with start and reset.
