Chapter 3
KEYPAD FUNCTIONS
3.4 Programming Mode
The Programming mode provides you with these functions--setting and checking function code data,
monitoring maintenance information and input/output (I/O) terminal status. The functions can be easily
selected with the menu-driven system. Table 3.4-1 lists menus available in Programming mode. The
leftmost digit (numerals) of each letter string on the LED monitor indicates the corresponding menu
number and the remaining three digits indicate the menu contents.
When the inverter enters Programming mode from the second time on, the menu selected last in
Programming mode will be displayed.
Table 3.4-1 Menus Available in Programming Mode
Menu
#
Menu
LED
monitor
display
Main functions Refer to:
0 Quick setup
*fnc
Displays only basic function codes to customize the
inverter operation.
Section
3.4.1.
!f__
F codes
(Fundamental functions)
!e__
E codes
(Extension terminal functions)
!c__
C codes
(Control functions)
!p__
P codes
(Motor 1 parameters)
!h__
H codes
(High performance functions)
!a__
A codes
(Motor 2 parameters)
!b__
b codes
(Motor 3 parameters)
!r__
r codes
(Motor 4 parameters)
!j__
J codes
(Application functions 1)
!d__
d codes
(Application functions 2)
!u__
U codes
(Application functions 3)
!y__
y codes
(Link functions)
1 Data setting
!o__
o codes
(Option function) (Note)
Selecting each of
these function
codes enables its
data to be
displayed/
changed.
Section
3.4.2.
2 Data checking
"rep
Displays only function codes that have been changed from
their factory defaults. You can refer to or change those
function code data.
Section
3.4.3.
3 Drive monitoring
#ope
Displays the running information required for maintenance
or test running.
Section
3.4.4.
4 I/O checking
$i_o
Displays external interface information.
Section
3.4.5.
5
Maintenance
information
%che
Displays maintenance information including cumulative run
time.
Section
3.4.6.
6 Alarm information
&al
Displays the recent four alarm codes. You can refer to the
running information at the time when the alarm occurred.
Section
3.4.7.
7 Data copying
'cpy
Allows you to read, write, and verify function code data.
Saving the function code data of the currently running
inverter into the keypad and connecting it to a PC running
FRENIC Loader enables data checking on the PC.
Section
3.4.8.
(Note) The o codes are displayed only when the corresponding option is mounted. For details, refer to the
Instruction Manual for the corresponding option.
To Next Page
