îš„ Assignment of Momentary power failure decelerating IPF2 (Function code data = 79)
When F14 is 2 or 3, the DC medium voltage decreases to H15 "Continuous running level" or lower, and the
signal turns on when the conditions turns to continuous running level. After restoration of power, when the
DC medium voltage increases to "set voltage of H15 + 10 V or higher," the signal turns off. Even when F14 is
4 or 5, the signal turns on when the DC medium voltage decreases to the undervoltage detected level or
lower, the signal turns on. The signal turns off when the voltage becomes "Undervoltage level + 10 V or
higher." (

Function code F14, H15)
îš„ Assignment of positioning completion signal PSET (Function code data = 82)
This output signal comes on as a positioning completion signal. (

Function code J97 to J99)
îš„ Assignment of maintenance timer MNT (Function code data = 84)
This function outputs an ON signal when the cumulative run time of the motor 1 exceeds the preset time or
when the startup time of the motor 1 exceeds the preset count.
(

Function code H78, H79)
îš„ Assignment of alarm details signals AL1, AL2, AL4, and AL8 (Function code data = 90, 91, 92, 93)
This function outputs the operation status of the inverter protection function.
Table 5.4-78
Output Terminal
Alarm Content (Inverter Protection Function) Alarm Code
AL1 AL2 AL4 AL8
Instantaneous overcurrent protection, ground
fault protection, and melting fuse
0c1-0c2-0c3
ef-fus
ON OFF OFF OFF
Overvoltage protection
0u1-0u2-0u3
OFF ON OFF OFF
Undervoltage protection, input open phase
protection
lu-lin
ON ON OFF OFF
Motor overload, electric thermal (motor 1 to 4)
0l1-0l2-0l3-0l4
OFF OFF ON OFF
Inverter overload
0lu
ON OFF ON OFF
INV overheat protection, Inverter overheat
0h1-0h3
OFF ON ON OFF
External alarm, DB resistor overheat, Motor
overheat
0h2-dbh-0h4
ON ON ON OFF
Memory abnormal, CPU error, save error in
undervoltage, hardware error
er1-er3-erf-erh
OFF OFF OFF ON
Keypad communication error, option
communication error
er2-er4
ON OFF OFF ON
Option abnormal
er5
OFF ON OFF ON
Charger circuit fault, Operation procedure error,
EN circuit fault, DB transistor malfunction detect
pbf-er6-ecf-dba
ON ON OFF ON
Tuning error, output phase loss protection
er7-0pl
OFF OFF ON ON
RS485 communication error
er8-erp
ON OFF ON ON
Overspeed protection, PG Error, excessive
position deviation, speed mismatch (excessive
speed deviation), Position control error
0s-pg-ere-do-ero
OFF ON ON ON
NTC thermistor (motor) breaking detect, PID
feedback breaking detect, Mock alarm
nrb-cof-err
ON ON ON ON
* In the normal condition, signals are not output from any terminal.
îš„ Assignment of light alarm L-ALM (Function code data = 98)
This function outputs an ON signal when a light alarm occurs. (

Function code H81, H82)
