11.4 Option
11-63
Chapter 11 SELECTING PERIPHERAL EQUIPMENT
[8] IP40 kits (P40G1-)
(1) Overview
Mounting the IP40 kit on the FRENIC-MEGA standard model 1 (basic type) enables the inverter's
enclosure to be totally encolosed (IP40).
(2) Configuration
Table 11.4-28
(3) Specifications
This kit is applicable only to the FRENIC-MEGA standard model 1 (basic type).
The specifications of the FRENIC-MEGA equipped with this kit differ from those of the standard model 1
(basic type) as listed below. Other specifications are the same as the standard model 1 (basic type).
Applicable inverter
Table 11.4-29
Inverter series Inverter capacity
FRENIC-MEGA 0.4 kW to 22 kW
Type and mass
Table 11.4-30
Item Specifications
Type (P40G1-) 0.75 3.7 11 22
Applicable inverter type (FRNG1S-2/4)
0.4 0.75 1.5 2.2 3.7 5.5 7.5 11 15 18.5 22
Weight / Mass (kg) 0.1 0.2 0.3 0.4
