11.4 Option
11-86
[11] Analog interface card (OPC-G1-AIO)
The analog interface card has the terminals listed below. Mounting this interface card on the
FRENIC-MEGA enables analog input and analog output to/from the inverter.
• One analog voltage input point (0 to ±10 V)
• One analog current input point (4 to 20 mA)
• One analog voltage output point (0 to ±10 V)
• One analog current output point (4 to 20 mA)
Ports available for the communications card
This interface card can be connected to any one of the three option connection ports (A-, B-, and C-ports)
on the FRENIC-MEGA.
Applicable ROM version
This interface card is applicable to inverters with a ROM version G1S10700 or later.
Terminal functions
Table 11.4-59
Class
Terminal
Signal
Name Explanation Remarks
[P10]
Power supply
for the
potentiometer
Used as power supply for frequency command
potentiometer (Variable resistor: 1 to 5 kΩ)
(10 VDC, 10 mA DC max.)
[32]
Analog voltage
input
• Used as voltage input for frequency command
0 to ±10 VDC/0 to±100% (0 to ±5 VDC/0 to
±100%)
• One of the followings can be assigned to this
terminal.
• Auxiliary frequency command
• PID command
• PID feedback value • Ratio setting
• Torque limiter level
• Analog input monitor
• Resolution: 1/3000
Input impedance
: 22 kΩ
Max. input:
±15 VDC
[C2]
Analog current
input
• Used as current input for frequency command
4 to 20 mA DC/0 to 100%
• One of the followings can be assigned to this
terminal.
• Auxiliary frequency command
• PID command
• PID feedback value • Ratio setting
• Torque limiter level
• Analog input monitor
• Resolution: 1/3000
Input impedance
: 250 Ω
Max. input:
30 mA DC
Analog input
[31]
Analog
common
• Reference terminal for frequency command
signals [P10], [32], [C2].
Equipotent with
the inverter's
terminal [11]
