11.4 Option
11-104
[16] DeviceNet communications card (OPC-G1-DEV)
The DeviceNet communications card is used to connect the FRENIC-MEGA series to a DeviceNet master
via DeviceNet. Mounting the communications card on the FRENIC-MEGA enables the user to configure
and monitor run and frequency commands and change and check inverter's function codes required for
running from the DeviceNet master.
Applicable ports
This communications card can be connected to any one of the three option connection ports (A-, B-, and
C-ports) provided on the FRENIC-MEGA.
Note: Once the inverter is equipped with this communications card, no more communications card (e.g.,
CC-Link and SX-bus communications cards) is allowed on the inverter. Mounting more than one card on
the inverter causes the er4 trip that cannot be reset until those cards are removed except a single card.
Applicable ROM version
This communications card is applicable to inverters with a ROM version G1S10500 or later.
DeviceNet specifications
Table 11.4-79
Item Specifications
Number of nodes connectable Max. 64 (including the master)
MAC ID 0 to 63
Insulation 500 VDC (photocoupler insulation)
Transmission speed 500, 250, 125 kbps
Transmission speed 500 kbps 250 kbps 125 kbps
Trunk line length 100 m 250 m 500 m
Drop line length 6 m 6 m 6 m
Maximum cable length
 (When using thick cables)
Total length of drop lines 39 m 78 m 156 m
Messages supported 1. I/O Message (Poll, Change of State)
2. Explicit Message
Vendor ID 319 (Registered name: Fuji Electric Group)
Device type AC drive (code: 2)
Product code 9219
Applicable device profile AC Drive
Number of input/output bytes Max. 8 bytes for each of input and output
* Depending on the format selected. Refer to "Communications
formats" on page 11-106.
Applicable DeviceNet
Specifications
CIP Specifications
Volume 1, Edition 2.2 Japanese version and Volume 3, Edition 1.1
Japanese version
Node type Group 2 only server (noncompliant with UCMM)
Network power consumption 80 mA, 24 VDC
Note: The network power is supplied by an external power source.
For the items not contained in the table above, the DeviceNet Specifications apply.
