[14] CC-Link communications card (OPC-G1-CCL)
CC-Link (Control & Communication Link) is an FA open field network system.
The CC-Link communications card connects the inverter to a CC-Link master unit via CC-Link using a
dedicated cable. It supports the transmission speed of 156 kbps to 10 Mbps and the total length of 100 to
1,200 m so that it can be used in wide range of systems requiring a high-speed or long-distance
transmission, enabling a flexible system configuration.
Applicable ports
This communications card can be connected to the A-port only, out of three option connection ports (A-, B-,
and C-ports) provided on the FRENIC-MEGA.
Note: Once the inverter is equipped with this communications card, no more communications card (e.g.,
DeviceNet and SX-bus communications cards) is allowed on the inverter. Mounting more than one card on
the inverter causes the
er4
trip that cannot be reset until those cards are removed except a single card.
Applicable ROM version
This communications card is applicable to inverters with a ROM version G1S10500 or later.
CC-Link specifications
Table 11.4-70
Item Specifications
Applicable controller Mitsubishi Electric sequencer, etc. (CC-Link master)
Transmission system
CC-Link version 1.10 and 2.0
(Broadcast polling system)
No. of supported inverters Max. 42 units (one station occupied/unit)
Number of stations occupied
CC-Link version 1.10: 1 station occupied
CC-Link version 2.0: 1 station occupied (Selectable from among
2X, 4X and 8X settings)
Transmission speed 10 Mbps/5 Mbps/2.5 Mbps/625 kbps/156 kbps
10 Mbps 5 Mbps 2.5 Mbps 625 kbps 156 kbps
Maximum cable length
(When using the CC-Link
dedicated cable)
100 m 150 m 200 m 600 m 1200 m
Insulation 500 VDC (photocoupler insulation)
Station type Remote device station
Remote device type Inverter (0x20)
For items not contained in the above table, the CC-Link specifications apply.
