5.3 Code Index by Purpose
5-40
5.3.4 Starting/stopping the motor
Table 5.3-6
To
Function
code
Name
Refer to
page:
Starting
frequency
Start the motor smoothly.
F23
F24
Starting Frequency 1 Starting
Frequency 1 (Holding time)
5-96
Auto search
Search for the idling motor speed to restart the
motor without stopping and shock.
H09
H49
H46
E01 to E09
Starting Mode
(Auto search)
(Auto search delay time 1)
(Auto search delay time 2)
Terminal [X1] to [X9] Functions
(STM)
5-184
5-122
Pre-excitation
Compensate for insufficient torque (due to
magnetic flux lag) at startup to accelerate the
motor promptly.
H84
H85
E01 to E09
Pre-excitation
(Initial level)
(Time)
Terminal [X1] to [X9] Functions
(EXITE)
5-205
5-122
Stop the motor smoothly.
Stopping the
motor
Prevent torque from being insufficient in a low
speed zone when stopping the motor.
F25
F38
F39
Stop Frequency
Stop Frequency (Detection mode)
Stop Frequency (Holding time)
5-96
Prevent the motor from running by inertia during
decelerate-to-stop operation with DC braking.
F20
F21
F22
H95
DC Braking 1
(Braking starting frequency)
(Operation level)
(Braking time)
(Braking response mode)
5-94
DC braking
Apply DC braking with a terminal command
sent from external equipment.
E01 to E09
Terminal [X1] to [X9] Functions
(DCBRK)
5-122
Force to stop Use the forced stop function for safety.
H56
E01 to E09
Deceleration Time for Forced
Stop
Terminal [X1] to [X9] Functions
(STOP)
5-76
5-122
Coast to a stop Use the coast-to-stop function for safety. E01 to E09
Terminal [X1] to [X9] Functions
(BX)
5-122
5.3.5 Specifying the acceleration/deceleration (time, mode, and pattern)
Table 5.3-7
To
Function
code
Name
Refer to
page:
Acceleration/
deceleration time
Accelerate or decelerate the motor within the
specified time.
F07
F08
Acceleration Time 1
Deceleration Time 1
5-76
Switch between
ACC/DEC times
Switch the acceleration or deceleration time.
E01 to E09
E10
E11
E12
E13
E14
E15
Terminal [X1] to [X9] Functions
(RT1, RT2)
Acceleration Time 2
Deceleration Time 2
Acceleration Time 3
Deceleration Time 3
Acceleration Time 4
Deceleration Time 4
5-122
5-76
Allow the motor to coast to a stop when the run
command is turned OFF in order to minimize
the variation of deceleration torque.
Coast-to-stop
Allow the motor to coast to a stop in order to
prevent conflict with the mechanical brake.
H11 Deceleration Mode 5-186
S-curve
acceleration/dec
eleration
Apply S-curve to the acceleration/deceleration
pattern to gradually accelerate/decelerate the
motor to reduce an impact that
acceleration/deceleration would make on the
machinery.
H07
H57
H58
H59
H60
Acceleration/Deceleration Pattern
1st S-curve acceleration range
(Leading edge)
2nd S-curve acceleration range
(Trailing edge)
1st S-curve deceleration range
(Leading edge)
2nd S-curve deceleration range
(Trailing edge)
5-76
Curvilinear
acceleration/dec
eleration
Select the curvilinear acceleration/deceleration
pattern to accelerate or decelerate the motor
with its maximum performance.
H07
Curvilinear
acceleration/deceleration
5-76
