12.1 Standard Model 1 (Basic Type)
12-2
*7 Average braking torque for the motor running alone. (It varies with the efficiency of the motor.)
*8 For inverters with a capacity of 55 kW, a DCR is provided as standard or option for LD or HD mode, respectively.
12.1.2 Three-phase 400 V class series
HD (High Duty)-mode inverters for heavy load (0.4 to 75 kW)
Item Specifications
Type (FRN***G1S-4J) 0.4 0.75 1.5 2.2 3.7 5.5 7.5 11 15 18.5 22 30 37 45 55 75
Nominal applied motor
(kW)
*1
(Output rating)
0.4 0.75 1.5 2.2 3.7 5.5 7.5 11 15 18.5 22 30 37 45 55 75
Rated capacity (kVA)
*2
1.1 1.9 2.8 4.1 6.8 10 14 18 24 29 34 45 57 69 85 114
Rated voltage (V)
*3
Three-phase 380 to 480 V (with AVR function)
Rated current (A) 1.5 2.5 4.0 5.5 9.0 13.5 18.5 24.5 32 39 45 60 75 91 112 150
Output ratings
Overload capability 150%-1 min, 200%-3.0 s
Voltage, frequency 380 to 480 V, 50/60 Hz
*9
Allowable
voltage/frequency
Voltage: +10 to -15% (Interphase voltage unbalance: 2% or less)
*5
, Frequency: +5 to -5%
Input power
Required capacity
(with DCR) (kVA)
*6
0.6 1.2 2.1 3.2 5.2 7.4 10 15 20 25 30 40 48 58 71 96
Torque (%)
*7
150% 100% 20% 10 to 15%
Braking transistor Built-in －
Built-in braking resistor
Braking time (s)
5 s －
Braking
Duty cycle (%ED) 5 3 5 3 2 3 2 －
DC reactor (DCR)
*8
Option
Provided
as
standard
Applicable safety
standards
UL508C, C22.2 No.14, IEC/EN61800-5-1:2007
Enclosure (IEC60529) IP20, UL enclosed type IP00, UL open type
Cooling method Natural cooling Fan cooling
Weight / Mass (kg) 1.7 2.0 2.6 2.7 3.0 6.5 6.5 5.8 9.5 9.5 10 25 26 31 33 42
(90 to 630 kW)
Item Specifications
Type (FRN***G1S-4J) 90 110 132 160 200 220 280 315 355 400 500 630
Nominal applied motor
(kW)
*1
(Output rating)
90 110 132 160 200 220 280 315 355 400 500 630
Rated capacity (kVA)
*2
134 160 192 231 287 316 396 445 495 563 731 891
Rated voltage (V)
*3
Three-phase 380 to 480 V (with AVR function)
Rated current (A) 176 210 253 304 377 415 520 585 650 740 960 1170
Output ratings
Overload capability 150%-1 min, 200%-3.0 s
Voltage, frequency
380 to 440 V, 50 Hz
380 to 480 V, 60 Hz
Allowable
voltage/frequency
Voltage: +10 to -15% (Interphase voltage unbalance: 2% or less)
*5
, Frequency: +5 to -5%
Input power
Required capacity
(with DCR) (kVA)
*6
114 140 165 199 248 271 347 388 436 489 611 773
Torque (%)
*7
10 to 15%
Braking transistor －
Built-in braking resistor
Braking time (s)
－
Braking
Duty cycle (%ED) －
DC reactor (DCR)
*8
Provided as standard
Applicable safety
standards
*10
UL508C, C22.2 No.14, IEC/EN61800-5-1:2007
Enclosure (IEC60529) IP00, UL open type
Cooling method Fan cooling
Weight / Mass (kg) 62 64 94 98 129 140 245 245 330 330 530 530
*1 Fuji 4-pole standard motor
*2 Rated capacity is calculated assuming the rated output voltage as 220 V for 200 V class series and 440 V for 400 V class
series.
*3 Output voltage cannot exceed the power supply voltage.
*5 Voltage unbalance (%) = Max. voltage (V) - Min. voltage (V) / Three-phase average voltage (V) × 67 (IEC/EN61800-3)
If this value is 2 to 3%, use an optional AC reactor (ACR).
*6 Required when a DC reactor (DCR) is used.
*7 Average braking torque for the motor running alone. (It varies with the efficiency of the motor.)
