App. D Inverter Generating Loss
A-20
App. D Inverter Generating Loss
The table below lists the inverter generating loss.
Table D-1
Generating loss (W)
HD mode MD mode LD mode
Power
supply
voltage
Inverter type
Low carrier: High carrier: Low carrier: Low carrier: High carrier:
FRN0.4G1-2J 35 45 - - -
FRN0.75G1-2J 50 60 - - -
FRN1.5G1-2J 80 110 - - -
FRN2.2G1-2J 110 140 - - -
FRN3.7G1-2J 170 210 - - -
FRN5.5G1-2J 240 310 - 290 370
FRN7.5G1-2J 300 415 - 410 550
FRN11G1-2J 450 620 - 500 670
FRN15G1-2 540 700 - 630 840
FRN18.5G1-2J 660 860 - 770 970
FRN22G1-2J 790 1040 - 1120 1250
*1
FRN30G1-2J 1300 1450 - 1650 1750
*1
FRN37G1-2J 1300 1550 - 1650 1850
*1
FRN45G1-2J 1450 1600 - 1850 1950
*1
FRN55G1-2J 1750 1900 - 2250 2400
*1
FRN75G1-2J 2300 2550
*1
- 2700 2800
*2
Three-
phase
200 V
FRN90G1-2J 2750 3050
*1
- 3250 3350
*2
FRN0.4G1-4J 35 60 - - -
FRN0.75G1-4J 45 80 - - -
FRN1.5G1-4J 60 110 - - -
FRN2.2G1-4J 80 140 - - -
FRN3.7G1-4J 130 230 - - -
FRN5.5G1-4J 170 300 - 210 370
FRN7.5G1-4J 230 400 - 300 520
FRN11G1-4J 300 520 - 360 610
FRN15G1-4J 360 610 - 460 770
FRN18.5G1-4J 440 770 - 510 870
FRN22G1-4J 510 900 - 710 1310
*1
FRN30G1-4J 800 1150 - 1000 1250
*1
FRN37G1-4J 1000 1450 - 1250 1550
*1
FRN45G1-4J 1100 1600 - 1350 1700
*1
FRN55G1-4J 1350 1950 - 1950 2400
*1
FRN75G1-4J 1600 2150
*1
- 2000 2250
*2
FRN90G1-4J 1900 2600
*1
2250 2250 2550
*2
FRN110G1-4J 2300 3050
*1
2700 2700 3050
*2
FRN132G1-4J 2500 3300
*1
3050 3050 3400
*2
FRN160G1-4J 3100 4000
*1
3900 3900 4350
*2
FRN200G1-4J 3850 5000
*1
4250 4250 4750
*2
FRN220G1-4J 4350 5600
*1
4850 5600 6200
*2
FRN280G1-4J 5300 6900
*1
5850 6500 7300
*2
FRN315G1-4J 6000 7800
*1
6650 7500 8350
*2
FRN355G1-4J 6450 8450
*1
7250 8100 9100
*2
FRN400G1-4J 7350 9650
*1
8250 9200 10350
*2
FRN500G1-4J 9600 10700
*2
- 11550 12950
*2
Three-
phase
400 V
FRN630G1-4J 11900 13300
*2
- 13500 13800
*3
Note: A box () in the above table replaces an alphabetic letter depending on the enclosure.
S (Basic type), E (EMC filter built-in type)
Low carrier: 2 kHz
High carrier: 22 kW or less: 16 kHz (*1: 10 kHz)
30 kW or above 15 kHz (*1: 10 kHz, *2: 6 kHz, *3: 4 kHz)
