Fuji Electric Frenic Mega Series User Manual

5.3 Code Index by Purpose
5-54
5.3.14 Customizing the keypad
Table 5.3-21
To
Function
code
Name
Refer to
page:
Protect function code data from accidentally getting changed.
F00
E01 to E09
Data Protection
Terminal [X1] to [X9] Functions
(WE-KP)
5-61
5-122
Revert function code data to the initial values.
Initialize motor parameters.
H03 Data initialization 5-181
Remove restrictions on the menu display to use various checking
functions on the keypad.
E52 Keypad (Menu display mode) 5-161
Suppress fluctuation of unstable, hard-to-read display on the
keypad.
E42 LED Display Filter 5-156
Specify the running status item to be monitored and displayed on
the LED monitor.
E43
E48
LED Monitor (Item selection)
LED Monitor (Speed monitor
item)
5-157
Display the output frequency even when the inverter is stopped. E44
LED Monitor (Display when
stopped)
5-158
Set up the display items for the multi-function keypad.
E45
E46
E47
LCD Monitor
(Item selection)
(Language selection)
(Contrast control)
-
E61
E62
E63
Terminal [12] Extended Function
Terminal [C1] Extended Function
Terminal [V2] Extended Function
5-162
Receive external analog sensor signals from sensors and convert
their values into physical quantities to display.
E40
E41
PID Display Coefficient A
PID Display Coefficient B
5-155
Display the load shaft speed and line speed. E50 Coefficient for speed indication 5-160
Display the input watt-hour data (kWh) multiplied by a display
coefficient.
E51
Display Coefficient for Input
Watt-hour Data
5-160
Convert a PID command and its feedback into physical quantities
to display.
E40
E41
PID Display Coefficient A
PID Display Coefficient B
5-155
5.3.15 Controlling the inverter via communications line
Table 5.3-22
To:
Function
code
Name
Refer to
page:
Specify communications conditions.
y01
y02
y03
y04
y05
y06
y07
y08
y09
y10
SW3
RS-485 Communication 1
(Station address)
(Communications error
processing)
(Timer)
(Baud rate)
(Data length)
(Parity bit selection)
(Stop bit selection)
(No-response error detection
time)
(Response interval)
(Protocol selection)
< Switching the terminating
resistor of the RS-485
communications port 1 >
5-272
2-34
