5.3 Code Index by Purpose
5-42
5.3.7 Controlling the motor
[1] Motor drive control to be selected
Table 5.3-9
To
Function
code
Name
Refer to
page:
Drive control
Select the motor drive control (e.g., V/f or vector
control) suited for the characteristics of the
machinery (load).
F42 Drive Control Selection 1 5-114
Slip
compensation
Improve the motor speed control accuracy by
compensating for the decrease (slip) in motor
rotation.
H68
Slip Compensation 1 (Operating
conditions)
5-114
Control the speed control sequence in normal
operation.
d01
d02
d03
d04
d05
d06
Speed Control 1
(Speed command filter)
(Speed detection filter)
P (Gain)
I (Integral time)
(Feed forward gain)
(Output filter)
5-235
Apply a speed zero command. d24 Zero Speed Control 5-96
Apply a servo-lock command.
*1
(Available only under vector control with speed
sensor.)
E01 to E09
E20 to E24
J97
J98
J99
d27
d28
Terminal [X1] to [X9] Functions
(LOCK)
Terminal [X1] to [X9] Functions
(SLG2)
Terminal [Y1] to [Y5A/C]
Functions (PSET)
Servo-lock
(Gain)
(Completion timer)
(Completion range)
(Gain 2)
(Gain switch time)
5-122
5-141
5-233
Control the speed control sequence for jogging
operations to obtain higher speed response
than that of normal operations.
d09
d10
d11
d12
d13
Speed control (Jogging)
(Speed command filter)
(Speed detection filter)
P (Gain)
I (Integral time)
(Output filter)
5-239
Speed control
under vector
control
Customize the speed feedback input. (Available
only under vector control with speed sensor.)
d14
d15
d16
d17
Feedback Input (Pulse input
format)
(Pulse input format)
(Encoder pulse resolution)
(Pulse count factor 1)
(Pulse count factor 2)
5-239
*1 Available for inverters with ROM version 0500 or later.
To Next Page
