5.4.5 H codes (High performance functions)
H03
Data Initialization
Initialize function code data to the factory defaults. In addition, initialization of the motor parameter is
executed.
To change the H03 data, it is necessary to press the " key + / keys" (simultaneous keying).
Table 5.4-108
Data for H03 Function
0 Manual setting value (no initialization executed)
1 Initial value (initializes all function code data to the factory defaults)
2 Initialize motor 1 parameters (according to motor 1 selection (P99) and motor capacity (P02)
3 Initialize motor 2 parameters (according to motor 2 selection (A39) and motor capacity (A16)
4 Initialize motor 3 parameters (according to motor 3 selection (b39) and motor capacity (b16)
5 Initialize motor 4 parameters (according to motor 4 selection (r39) and motor capacity (r16)
- To initialize the motor parameters, set the related function codes as follows.
Table 5.4-109
Function Code
Step Item Contents
1st motor
(Default codes)
2nd motor 3rd motor 4th motor
(1) Motor selection
Select the type of
applying motor
P99 A39 b39 r39
(2) Motor (capacity)
Set the capacity (kW)
of the applying motor
P02 A16 b16 r16
(3)
Data
initialization
Initialize motor parameters H03 = 2 H03 = 3 H03 = 4 H03 = 5
In "motor selection,"
when data = 0, 1, 3, and 4
is set
P01, P03, P06
to P23, P53 to
P56, H46
A15, A17,
A20 to A37,
A53 to A56
b15, b17,
b20 to b37,
b53 to b56
r15, r17, r20
to r37, r53 to
r56
Function code
to be initialized
In "motor selection,"
adding only when data = 2
is set
F04, F05 A02, A03 b02, b03 r02, r03
- Upon completion of the initialization, the function code H03 data reverts to "0" (factory default).
- If P02/A16/b16/r16 data is set to a value other than the standard motor capacity, data is automatically
changed to the standard motor capacity (See Table 5.2-18 given on the last page of "5.2 Function Code
Tables.").
- Motor parameters to be initialized are for motors listed below under V/f control. When a motor with a
different base frequency, rated voltage, and number of poles is used, or when non-Fuji motors or motors
with a different series are used, change the current to the one indicated on the motor nameplate.
Table 5.4-110
Motor selection V/f setting
Data = 0, 4 Fuji standard motors, 8-series 4 poles 200 V/50 Hz, 400 V/50 Hz
Data = 2
Motors exclusively designed for Fuji
vector control
4 poles ―/50 Hz, ―/50 Hz
Data = 3 Fuji standard motors, 6-series 4 poles 200 V/50 Hz, 400 V/50 Hz
Data = 1 HP indication motors 4 poles 230 V/60 Hz, 460 V/60 Hz
When P02 is changed from the keypad, take note that P03, P06 through P23, P53 through P56,
and H46 automatically change. Also, when A16, b16, or r16 for the 2nd to 4th motors are changed,
take note that the related function codes are automatically changes.
When P02/A16/b16/r16 is changed from the communication, other function codes are not
automatically re-written.
