5.3 Code Index by Purpose
5-37
Chapter 5 Function Code
5.3 Code Index by Purpose
5.3.1 Configuring the minimal requirements for the inverter to just run the motor
To run the motor simply with constant torque load under V/f control, the following function codes should be
configured as minimal requirements. These function codes are displayed in the quick setup
.
Table 5.3-1
To
Function
code
Name
Refer to
page:
Set the command source that specifies reference frequency. F01 Frequency Command 1 5-62
Select the source that specifies a run command that runs or stops
the motor.
F02 Operation Method 5-71
Specify the maximum frequency to limit the output frequency
(motor rotation).
F03 Maximum Output Frequency 1 5-72
Limit the reference frequency. F16 Frequency Limiter (Low) 5-93
Enter the motor ratings printed on its nameplate to run the motor
properly.
F04
F05
F06
Base Frequency 1
Rated Voltage at Base Frequency 1
Maximum Output Voltage 1
5-72
Specify the acceleration/deceleration time.
F07
F08
Acceleration Time 1
Deceleration Time 1
5-76
Adjust the output voltage with the torque boost to secure a
sufficient starting torque.
F09 Torque Boost 1 5-79
Protect the motor.
F10
F11
Electronic Thermal Overload
Protection for Motor 1
(Select motor characteristics)
(Operation level)
5-80
Select the restart mode to apply after momentary power failure. F14
Restart Mode after Momentary
Power Failure (Mode selection)
5-83
Reduce an audible noise generated by the motor. F26 Motor Sound (Carrier frequency) 5-99
Remove restrictions on the menu display to use various checking
functions on the keypad.
E52 Keypad (Menu display mode) 5-161
Specify the motor parameters.
P02
P03
P04
P99
Motor 1
(Rated capacity)
(Rated current)
(Auto-tuning)
Motor 1 Selection
5-175
5-176
5-177
5-180
5.3.2 Setting up the frequency
[1] Frequency setting from the keypad
Table 5.3-2
To
Function
code
Name
Refer to
page:
Set up the reference frequency from the keypad.
F01
E64
Frequency Command 1
Saving of Digital Reference
Frequency
5-62
5-163
[2] Frequency setting by analog input
Table 5.3-3
To
Function
code
Name
Refer to
page:
Set up the reference frequency using analog input (voltage or
current) applied to terminal [12], [C1], or [V2] from external
equipment (analog frequency command source).
F01 Frequency Command 1 5-62
