5.3 Code Index by Purpose
5-43
Chapter 5 Function Code
Table 5.3-10
To
Function
code
Name
Refer to
page:
A42
d25
E01 to E09
Motor/Parameter Switching 2
ASR Switching Time Terminals
[X1] to [X9] Functions (M2)
5-211
5-122
d01
d02
d03
d04
d05
d06
Speed Control 1
(Speed command filter)
(Speed detection filter)
P (Gain)
I (Integral time)
(Feed forward gain)
(Output filter)
5-235
Switch the gain and other speed control
parameters between two control modes.
A43
A44
A45
A46
A47
A48
Speed Control 2
(Speed command filter)
(Speed detection filter)
P (Gain)
I (Integral time)
(Feed forward gain)
(Output filter)
-
Speed control
under vector
control
Decrease the speed loop gain only in the
vicinity of the predetermined resonance points,
suppressing the mechanical resonance.
*2
(Only under vector control with speed sensor)
d07
d08
Speed Control 1
(Notch filter resonance
frequency)
(Notch filter attenuation level)
5-238
Speed Control
Limiter
Specify a limiter for the PI value output
calculated in speed control sequence.
(Only under V/f control with speed sensor or
dynamic torque vector with speed sensor)
d70 Speed Control Limiter
5-248
Torque control
Control the motor-generating torque according
to a torque command sent from external
sources.
H18
E01 to E09
E61 to E63
E98, E99
Torque Control (Mode selection)
Terminal [X1] to [X9] Functions
Terminal [12], [C1], [V2] Extended
Functions
Terminal [FWD], [REV] Functions
5-187
5-122
5-162
5-165
*2 Available for inverters with ROM version 1000 or later.
[2] Motor parameters to be set up
Table 5.3-11
To
Function
code
Name
Refer to
page:
Use Fuji standard motors (6- or 8-series, 4P, 50 Hz) or Fuji motors
exclusively designed for vector control.
P99
P02
H03
Motor 1 Selection
Motor 1 (Rated capacity)
Data Initialization
5-180
5-175
5-181
Check the motor nameplate and specify the motor parameters.
P99
F04
F05
F06
F03
P01
P02
P03
Motor 1 Selection
Base Frequency 1
Rated Voltage at Base Frequency 1
Maximum Output Voltage 1
Maximum Output Frequency 1
Motor 1
(No. of poles)
(Rated capacity)
(Rated current)
5-180
5-72
5-175
5-176
Perform motor parameter tuning (offline). P04
Motor 1
(Auto-tuning)
5-177
To Next Page
