5.3 Code Index by Purpose
5-44
To
Function
code
Name
Refer to
page:
P06
P07
P08
P53,P54
P09
P10
P11
P12
P13 to P15
P16 to P20
P21 to P23
Motor 1
(No-load current)
(%R1)
(%X)
(%X correction factor 1, 2)
(Slip compensation gain for
driving)
(Slip compensation response
time)
(Slip compensation gain for
braking)
(Rated slip frequency)
(Iron loss factor 1 to 3)
(Magnetic saturation factor 1 to
5)
(Magnetic saturation extension
factor "a" to "c")
5-178
5-179
5-180
Set up motor parameters according to tuning or the motor
manufacturer's data sheet. (To use the data sheet, conversion is
required.)
P55
P56
Motor 1
(Torque current under vector
control) (Induced voltage factor
under vector control)
5-180
Identify a motor constant that has responded to changes in motor
temperature (Online tuning), and minimize speed fluctuation of the
motor.
*3
P05
Motor 1
(Online tuning)
5-178
*3 Available for inverters with ROM version 3000 or later.
5.3.8 Setting up I/O terminals
Table 5.3-12
To
Function
code
Name
Refer to
page:
Assignment of
functions to
general-purpose
input terminals
Assign functions (commands) to the digital input
terminals to control the inverter.
E01 to E09 Terminal [X1] to [X9] Functions 5-122
Assignment of
functions to
general-purpose
output terminals
Output inverter or motor running status to the
transistor or contact output signals.
E20 to E24
Terminal [Y1] to [Y5A/C]
Functions
5-141
Input/Output
signals
Apply negative logic to general-purpose
input/output.
E01 to E09
E20 to E24
Terminal [X1] to [X9] Functions
Terminal [Y1] to [Y5A/C]
Functions
5-122
5-141
5.3.9 Outputting monitored data
Table 5.3-13
To
Function
code
Name
Refer to
page:
Analog output
Output various monitored data for meters in an
analog DC voltage or current via terminal
[FMA].
F29
SW4
F30
F31
Analog Output [FMA] (Mode
selection)
<Voltage/current output switch for
terminal [FMA]>
(Gain to output voltage)
(Function selection)
5-101
2-34
Pulse output
Output various monitored data for meters in a
pulse train via terminal [FMP].
F33
F34
F35
Pulse Output [FMP]
(Pulse rate)
(Gain to output voltage)
(Function selection)
5-103
