3-180 Phaser 5500 Printer Service Manual
7
Check the Set Clamp Home Sensor signal.
Does the voltage across P8302B-11<=>
P8302B-9 on the Finisher Main PWB
change when the sensor is blocked?
Replace the
Finisher Main
PWB
(
page 3-248).
Replace the Set
Clamp
Home
Sensor
(
page 3-188).
8
Test the Eject Motor.
Run the Service Diagnostics Low Speed
Forward and Reverse Eject Motor tests.
Does the Eject Motor rotate normally?
Go to Step 15. Go to Step 9.
9
Check Eject Motor Harness connections.
Are P/J8336 and P/J8304 connected?
Go to Step 11. Connect and go
to Step 10.
10
Print a Test Print.
Does the error still occur?
Go to Step 11. Problem solved.
11
Check Eject Motor Harness continuity.
1. Disconnect P/J8336 and P/J8304.
2. Check for continuity at the following:
P/J8336-1 <=> P/J8304-15
P/J8336-2 <=> P/J8304-12
P/J8336-3 <=> P/J8304-17
P/J8336-4 <=> P/J8304-19
P/J8336-5 <=> P/J8304-14
P/J8336-6 <=> P/J8304-21
Are these conductive?
Go to Step 12. Repair the Eject
Motor Harness.
12
Check Eject Motor resistance.
Is there resistance across P8336-2/
5(COM) and P8336-1/3/4/6?
Go to Step 13. Replace the Eject
Bracket Assembly
(
page 3-187).
13
Check for +24 V to the Eject Motor.
Is there +24 V across J8304-12 <=>
ground, and J8304-14 <=> ground on
the Finisher Main PWB?
Go to Step 14. Replace the
Finisher Main
PWB
(
page 3-248).
14
Replace the Eject Clamp Motor.
Print a Test Print.
Does the error still occur?
Replace the
Finisher Main
PWB
(
page 3-248).
Problem solved.
15
Test the Set Clamp Clutch (Clutch Z34).
Run the Service Diagnostics Set Clamp
Clutch test.
Does the Set Clamp Clutch operate?
Replace the
Finisher Main
PWB
(
page 3-248).
Go to Step 16.
16
Check the Set Clamp Clutch Harness
connection.
Are P/J8338B and P/J8304 connected?
Go to Step 18. Connect and go
to Step 17.
17
Print a test Print.
Does the error still occur?
Go to Step 18. Problem solved.
Eject Clamp (Set Clamp Home Sensor) Troubleshooting Procedure (Continued)
Step Actions and Questions Yes No
To Next Page
