Commissioning | OEM area
7.4
OEM area
In the OEM area, commissioning engineers can customize the product in various
ways:
Documentation: Adding the OEM documentation, e.g. service information
Startup screen: Defining a startup screen with the OEM's company logo
Screenshots: Configuring the unit for screenshots with the program Screen-
shotClient
7.4.1 Adding documentation
You can store and display the product's documentation right on the product.
Only documents in the *.pdf file format can be added as a
documentation. The product does not display documents provided in
other file formats.
Tap Settings in the main menu
Tap Service
Open in the sequence
OEM area
Documentation
Add OEM service info
If required, connect a USB mass storage device (FAT32
format) to a USB port of the product
To navigate to the desired file, tap the location where the file
is stored
If you have accidentally tapped the wrong folder, you
can return to the previous folder.
Tap the file name that is displayed above the
list
Navigate to the folder containing the file
Tap the file name
Tap Select
The file is copied to the product’s Service info area
Further information: "Service info", Page 352
Confirm the successful transfer with OK
Further information: "Documentation", Page 388
Safely removing a USB mass storage device
Tap File management in the main menu
Navigate to the list of storage locations
Tap Safely remove
The message The storage medium can be removed now.
appears
Disconnect the USB mass storage device
7
HEIDENHAIN | QUADRA-CHEK 2000 | Operating Instructions | 07/2019
137
