HEIDENHAIN QUADRA-CHEK 2000 User Manual

Commissioning | Logging in for commissioning
7.2.2 Performing the reference mark search after startup
If the reference mark search after unit start is active, then all of the
unit’s functions will be disabled until the reference mark search has
been successfully completed.
Further information: "Reference marks (Encoder)", Page 381
The reference mark search does not need to be performed for serial
encoders with EnDat interface, because the axes are automatically
homed.
If the reference mark search is active on the unit, then a wizard will ask you to
traverse the reference marks of the axes.
After logging in, follow the instructions of the wizard
The Reference symbol stops blinking upon successful completion of the
reference mark search
Further information: "Operating elements of the position display", Page 80
Further information: "Activating the reference mark search", Page 107
7.2.3 Setting the language
The user interface language is English. You can change to another language, if
desired.
Tap Settings in the main menu
Tap User
The logged-in user is indicated by a check mark
Select the logged-in user
The language selected for the user is indicated by a national
flag in the Language drop-down list
Select the flag for the desired language from the Language
drop-down list
The user interface is displayed in the selected language
7
HEIDENHAIN | QUADRA-CHEK 2000 | Operating Instructions | 07/2019
99
